An upgraded suspension package pairs with cherry-picked components for snappy shifting and precise modulation on the trail.
Colors: Matte Galactic Grey to Black Fade, Matte Pennyflake, Deep Smoke & Mulsanne Blue
You want the feel of a playful trailbike, plus a little extra power on the climbs. You want upgrades where it counts the most, like a premium suspension package and the perfect blend of components. You don't want to lose out on the natural experience of mountain biking, and want a refined motor that quietly assists while you ride.
An OCLV Mountain Carbon frame equipped with a fully-encased 360Wh battery and TQ harmonic pin ring transmission with a smart charging port, integrated LED display and discreet handlebar remote. 150mm FOX Rhythm 36 fork with Float EVOL air spring and GRIP damper, and 140mm FOX Performance Float X rear suspension. Plus tubeless-ready wheels and tires, and a 12-speed drivetrain of cherry-picked Shimano SLX and XT components.
Fuel EXe 9.7 is a playful trail ride that gives you extra fuel in the tank on climbs, and rides like a traditional bike on descents. It's packed with the space-age technology of a TQ transmission, 150mm of buttery-smooth travel for soaking up rock gardens, and a cherry-picked drivetrain that gives you upgrades where it matters most.
We have this bike style in our Sunshine Demo Fleet! This can give you an opportunity to check out this amazing bike before you buy.
The best way to find your perfect fit is to consult the experts here at Sunshine Bicycle Center.
*spec applies to all sizes unless otherwise noted
Frame | OCLV Mountain Carbon, removable battery, internal routing, alloy rocker link, 34.9mm seat tube, upper chain guide mount, 55mm chainline, Mino Link, ABP, Boost148, UDH, 140mm travel |
---|---|
Fork | Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 150mm travel |
Shock | Fox Performance Float X, 2-position damper, 205mm x 60mm |
Wheel front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
---|---|
Wheel rear | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle |
Hub front | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle |
*Hub rear | Size: S, M, L, XL Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12mm thru axle |
Size: S, M, L, XL Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle |
|
Skewer rear | Bontrager Switch thru axle, removable lever |
Rim | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
Tire | Bontrager XR5 Team Issue, Tubeless Ready, aramid bead, 120 tpi, 29x2.50'' |
Tire part | Bontrager TLR sealant, 6oz |
Rim strip | Bontrager TLR |
Shifter | Shimano SLX M7100, 12 speed |
---|---|
Rear derailleur | Shimano XT M8100, long cage |
Crank | E*thirteen E*spec Plus, 34T, 165mm length |
Crank arm | E*thirteen E*spec Race alloy, 34T, 170mm length |
Chainring | E*thirteen E*spec, 32T alloy ring, 55mm chainline |
Cassette | Shimano SLX M7100, 10-51, 12 speed |
Chain | Shimano SLX M7100, 12 speed |
Saddle | Bontrager Arvada, austenite rails, 138mm width |
---|---|
*Seatpost | Size: S TranzX JD-YSP39, 100mm travel, internal routing, 34.9mm |
Size: M TranzX JD-YSP39, 150mm travel, internal routing, 34.9mm |
|
Size: L, XL TranzX JD-YSP39, 170mm travel, internal routing, 34.9mm |
|
Handlebar | Bontrager Line, alloy, 35mm, 27.5mm rise, 780mm width |
Grips | Bontrager XR Trail Elite, nylon lock-on |
Stem | Bontrager Elite, 35mm, 0 degree, 45mm length |
Brake | Shimano 4-piston hydraulic disc, M6100 lever, M6120 caliper |
*Brake rotor | Size: S, M, L, XL Shimano RT66, 6-bolt, 203mm |
Size: S, M, L, XL Shimano RT66, 6-bolt, 180mm |
Battery | TQ 360Wh |
---|---|
*Controller | Size: S, M, L, XL TQ LED display with Bluetooth & ANT+ connectivity |
Size: S, M, L, XL TQ handlebar mounted |
|
Motor | TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power |
Electronics | TQ 4A charger |
Weight | M - 19.05 kg / 42 lbs (with TLR sealant, no tubes) |
---|---|
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
